- 10 Stud Trailer Hub
- Hub Material: Cast
- Mounting Type: BSN
- Drum Type: Outboard
- Number of Studs: 10
- Bolt Circle: 11.25"
- Bearing Spacing: 3.34"
- Seal Bore: 6"
- Drum Pilot: 8.53"
- Hub Cap Bolt Circle: 5.50"
- Stud Description: 3/4"-16 Headed Stud
- Outer Bearing Cup: HM212011
- Outer Bearing Cone: HM212049
- Inner Bearing Cup: HM218210
- Inner Bearing Cone: HM218248
- ABS: No
- Stud Options
- Steel Wheels with Cast Drum: Use M3614 & M3615
- Steel Wheels with Centrifuse Drum: Use M3610 & M3611
- Aluminum Wheels with Cast Drum: Use M3241 & M3242
- Cross References: HT518K, 008-290-80, 220-00829080, 00829080, 008-290-79, 220-00829079, 00829079, 008-290-68, 220-00829068, 00829068, 008-290-67, 220-00829067, 00829067
