Thumbnail Filmstrip of Hub & Drum Assembly for Dexter 3.6K - 6K Axles with 12" x 2" Brakes, 6 on 5.5" Bolt Circle Images
- Hub & Drum Assembly
- Six 1/2" studs on 5.5" bolt circle
- Brake Size: 12" x 2"
- Capacity: 3,500 lbs.
- Inner Bearing Cone/Cup: 25580/25520 (Supplied with cup only, installed)
- Outer Bearing Cone/Cup: 15123/15245 (Supplied with cup only, installed)
- Seal: 1010 (Grease, Dexter) 1054 (Grease, Hayes) or 1063 (Oil equivalent to 1054 seal) (Not Included)
- Hub Cap: 211 (Not Included)
- Replaces Dexter# 008-201-09
- Cross References: 82019, 8-201-09, 00820109, 820109, 008-201-09, 008-484-05, 00848405, 09084604, 118800, 119000, 12200, 363239, 42656, 42656UC3, 8201, 82019UC3, 82019UC3E, 82109, 90817, B22012110, B220121108, C10938, D655, D655SW, HD1206HD, HD1206T, K08-484-90, K0848490, 9084604, 92655, A363239, RVDH655
