Thumbnail Filmstrip of Left Hand Camshaft, 1.50"-28 Spline, 1.625" Bearing Surface, Fits Meritor Q-Plus Trailer Axle Images
- Fits Meritor Q-Plus 16-1/2" brakes
- Splined Area: 1-1/2" - 28 Spline
- Bearing Surfaces: 1-5/8"
- Under Head to Snap Ring Groove: 24-1/16"
- Under Head to First Bearing Surface Groove: 1-11/16"
- Under Head to Second Bearing Surface Groove: 2"
- Cam Head Thickness: 1-3/16"
- Cross References: 2210B6869, 2210E6869S, 2210X6472, 2210X6576, M992L, M995L, E2445, E2445A, E2445AL, E2445ALH, E2445LH, E2451, E2451LH, E5510, E5510LH, E6081, E6081LH, 2210E6869, 2210P4332, R607068, 04932422, L3117, PROWCQ354L, TCQ10354L, WCQ354L
