Thumbnail Filmstrip of Right Hand Dana Spicer Trailer Axle Camshaft, 1.50"-28 Spline, 1.50" Bearing Surface Images
- Fits Dana Spicer Old Style S-Head 16-1/2" brakes
- Splined Area: 1-1/2" - 28 Spline
- Bearing Surfaces: 1-1/2"
- Under Head to Snap Ring Groove: 23-7/16"
- Under Head to First Bearing Surface Groove: 1-5/8"
- Under Head to Second Bearing Surface Groove: 2-7/32"
- Cam Head Thickness: 1-3/8"
- Cross References: CS41165, E3857, R607172
